Description
Tech Specs & Customization
Processor
Up to one Intel® Xeon® E-2200 product family processor with up to 8 cores per processor
Up to one Intel® Pentium® G5420 processor up to 2 cores per processor
Up to one Intel® Core i3® 9100 processor up to 4 cores per processor
Up to one Intel® Celeron® G4930 processor up to 2 cores per processor
Operating System
Canonical® Ubuntu® LTS
Citrix® Hypervisor®
Microsoft® Windows Server® LTSC with Hyper-V (2016 and 2019)
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
Bezel
Optional LCD or security bezel
Dimensions & Weight
Height
430.3mm (16.9″)
Width
218.0mm (8.6″)
Depth
603.0mm (23.7″)
Weight
26kg (55.67lbs.)
*Dimensions do not include bezel, PSU handle, or tower foot
Memory*
DIMM Speed
Up to 2666MT/s
Memory Type
UDIMM
Memory Module Slots
4 x DDR4 DIMM slots
Supports registered ECC DDR4 DIMMs only
Maximum RAM
UDIMM 64GB
Management
Embedded / At-the-Server
iDRAC9
iDRAC Direct
iDRAC RESTful API with Redfish
Consoles
OpenManage Enterprise
OpenManage Power Center
Mobility
OpenManage Mobile
Tools
Dell EMC RACADM CLI
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
iDRAC Service Module
IPMI Tool
OpenManage Server Administrator
OpenManage Storage Services
OpenManage Integrations
BM Truesight
Microsoft® System Center
RedHat® Ansible® Modules
VMware® vCenter
OpenManage Connections
IBM Tivoli® Netcool/OMNIbus
IBM Tivoli® Network Manager IP Edition
Micro Focus® Operations Manager I
Nagios® Core
Nagios® XI
Ports
Network options
2 X 1GbE
Front ports
1 x Dedicated iDRAC micro-USB
1 x USB 3.0
Rear ports
1 x Serial
4 x USB 2.0
2 x USB 3.0
1 x VGA
Internal Ports
1 x USB 3.0
Power Supplies
495W Platinum (Hot plug redundant)
350W Bronze (Cable)
Hot plug power supplies with full redundancy option
Slots
PCIe
1 x Gen3 slot (x16)
2 x Gen3 slots (x8)
1 x Gen3 slot (x1)
Video Card
1 x VGA
Storage
Front Bays
Up to 8 x 3.5″ SAS/SATA (HDD/SSD), max 112TB
(Also supports up to 8 x 2.5″ SAS/SATA (HDD) in 3.5″ hybrid drive carrier)
Storage Controllers
Internal Controllers
PERC H330, H730p, HBA330
External Controllers (non-RAID)
12 Gbps SAS HBA
Software RAID
S140
Internal BOOT
Boot Optimized Storage Subsystem (BOSS):
2 x M.2 240GB (RAID 1 or No RAID)
1 x M.2 240GB (No RAID only)
Internal Dual SD Module*
