Power-Saving Back-UPS Pro 900, 230V, Schuko

Description

Output
Output power capacity
540Watts / 900VA

Max Configurable Power (Watts)
540Watts / 900VA

Nominal Output Voltage
230V

Output Frequency (sync to mains)
50/60 Hz +/-1 Hz

Output Frequency (not synced)
50/60 Hz +/-1 Hz

Topology
Line Interactive

Output Connections
(2) Schuko CEE 7 (selector_surgetitle)
(3) Schuko CEE 7 (Battery Backup)
Transfer Time
8ms typical : 10 ms maximum

Input
Nominal Input Voltage
230V

Input frequency
50/60 Hz +/- 3 Hz (auto sensing)

Input Connections
Schuko CEE 7/7P

Cord Length
1.83meters

Input voltage range for main operations
176 – 294V

Input voltage adjustable range for mains operation
156 – 300V

Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Typical recharge time
8hour(s)

Replacement Battery
APCRBC123

Expected Battery Life (years)
3 – 5

RBC Quantity
1

Battery Volt-Amp-Hour Capacity
157

Runtime
View Runtime Graph
View Runtime Chart
Efficiency
View Efficiency Graph
Communications & Management
Interface Port(s)
Optional Simple Signalling RS232 cable , USB

Control panel
Multi-function LCD status and control console

Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering
Surge energy rating
613Joules

Data Line Protection
RJ-11 Modem/Fax/DSL protection (two wire single line), RJ45 10/100/1000 Base-T Ethernet protection

Filtering
Full time multi-pole noise filtering :10% of IEEE surge let-through : zero clamping response time: instantaneous

Physical
Maximum Height
250mm , 25.0cm

Maximum Width
100mm , 10.0cm

Maximum Depth
382mm , 38.2cm

Net Weight
10.73kg

Shipping weight
12.41kg

Shipping Height
487mm , 48.7cm

Shipping Width
225mm , 22.5cm

Shipping Depth
337mm , 33.7cm

Units per Pallet
30.0

Environmental
Operating Environment
0 – 40 °C

Operating Relative Humidity
0 – 95 %

Operating Elevation
0-3000meters

Storage Temperature
-15 – 45 °C

Storage Relative Humidity
0 – 95 %

Storage Elevation
0-15000meters

Audible noise at 1 meter from surface of unit
45.0dBA

Conformance
Approvals
BSI 1363, CE, GOST, NEMKO

Equipment protection policy
Lifetime : 200000 AUD, Lifetime : 150000 Euros, Lifetime : 75000 GBP

Standard warranty
2 years repair or replace, 3 years repair or replace for European Union countries

Sustainable Offer Status
RoHS
Compliant

REACH
REACH: Contains No SVHCs

PEP
Available in Documentation tab

EOLI
Available in Documentation tab
